Fully Automatic Multifunctional Microplate Reader CD-MB100

The fully automatic multifunctional microplate reader is a dedicated instrument for enzyme-linked immunosorbent assays (ELISA), based on fixed-wavelength optical filters. With a wavelength range of 340 nm–750 nm, it meets the needs of both scientific research and clinical applications. It is compatible with 96-well microplates, supporting various throughput requirements. Equipped with a 10.1-inch LCD display, it is user-friendly and requires no external keyboard. Data and programs can be stored within the instrument or exported via USB flash drive. This product is widely used in biological research, agricultural science, food science, and environmental science.

Send E-mail Get Price

86-15688870591

cedric@cedriccn.com

Description

Product Features:

· High-definition touchscreen: 10.1-inch color touchscreen with a resolution of 1280×800 pixels.

· Built-in software: Provides instrument control and data analysis; supports direct connection to USB drives.

· Long lamp life: Light source uses a 6V 10W halogen lamp with a service life of up to 2000 hours.

· Fast plate reading: Supports single-wavelength and dual-wavelength detection for rapid measurements.

· Shaking function: Configurable shaking function with adjustable time and speed.

· Operating system: Runs on a self-developed Android-based OS, enabling standalone operation, with multiple data output interfaces for flexible data transfer and processing.

· Visual plate layout: Supports visual plate layout for intuitive test result output.

· Absorbance range settings: 0–4.000 Abs, meeting diverse measurement requirements. Equipped with an 8-position filter wheel, standard configuration includes 4 filters. Optional filters covering 340–750 nm are available. Design allows lamp and filter replacement without opening the machine cover.

Product Specification:

Model	CD-MB100
System	10.1-inch color touchscreen, Android operating system
Reading Range	0-4.000 Abs
Filter Bandwidth	8-10 nm
Resolution	0.001 Abs
Wavelength Range	340-750 nm (covering the entire visible spectrum)
Linearity	0-3.0 Abs, ±1%; 3-4.0 Abs, ±2% (@405 nm)
Accuracy	±1% (0-3 Abs); ±2% (3-4 Abs) (@405 nm)
Filters	8-position filter wheel, 4 standard filters (405 nm, 450 nm, 492 nm, 630 nm); optional filters available (340-750 nm)
Measurement Speed	(<6 s per 96-well plate (fast measurement mode); Single wavelength: <15 s per 96-well plate; Dual wavelength: <28 s per 96-well plate (standard measurement mode))
Memory	Stores up to 200 measurement programs and 100,000 measurement results (96-well plates)
Interfaces	3 USB ports for computer, printer, and USB flash drive/barcode scanner
Light Source	6V 10W halogen lamp, service life up to 2000 hours
Dimensions	W440D295H225 mm
Power Supply	AC100–240V, 50–60Hz, 2A
Net Weight	10 kg

Optional Accessories：

Part No.	Accessory Name	Part No.	Accessory Name	Part No.	Accessory Name
TH010201	Filter 340 nm	TH010211	Filter 595 nm	TH010221	Filter 560 nm
TH010202	Filter 380 nm	TH010212	Filter 630 nm	TH010222	Filter 562 nm
TH010203	Filter 405 nm	TH010213	Filter 650 nm	TH010223	Filter 600 nm
TH010204	Filter 415 nm	TH010214	Filter 690 nm	TH010224	Filter 620 nm
TH010205	Filter 450 nm	TH010215	Filter 470 nm	TH010225	Filter 646 nm
TH010206	Filter 492 nm	TH010216	Filter 490 nm	TH010226	Neutral Density Filter 663 nm
TH010207	Filter 540 nm	TH010217	Filter 510 nm	TH010227	Filter 700 nm
TH010208	Filter 570 nm	TH010218	Filter 520 nm	TH010228	Filter 750 nm (Rapid)
TH010209	Filter 578 nm	TH010219	Filter 532 nm
TH010210	Filter 590 nm	TH010220	Filter 545 nm
