The shell is made of high-quality Galvanized sheet, with a surface treated by electrostatic spraying. It is elegant and generous in shape, and is anti-corrosive and durable.
The studio is processed and formed with 304 stainless steel and has undergone anti-corrosion treatment.
The height of the shelves is adjustable, and the four corners are in a semi-circular arc shape, which is convenient for cleaning.
The all-round three-dimensional forced air supply technology ensures uniform and consistent temperature inside the studio.
Double-layer tempered glass observation window. The height of the test sample shelf in the working chamber is adjustable, providing clear observation and convenient use.
86-175-5409-3886
cedric@cedriccn.com
Model | CHP-20C | CHP-45C | CHP-72C |
Capacity (L) | 20 L | 45 L | 72 L |
Rated power supply | 220 V 50 HZ | ||
Temperature control range | RT+5°C-65°C | ||
Temperature resolution | 0.1 | ||
Temperature fluctuation degree | ±0.5°C (At 37°C) | ||
Inner liner material | 304 stainless steel inner tank | ||
Shell material | Galvanized sheet (surface electrostatic spraying) | ||
Insulation layer | Ceramic fiber | ||
Heater | Stainless steel heating tube | ||
Material of the observation window | Tempered glass | ||
Exhaust hole (test hole) | One 35mm (top) | ||
Rated power | 180 W | 200 W | 300 W |
Timer | 0-999 min | ||
Operation function | Fixed value operation, timed operation, and automatic stop | ||
Sensor | PT100 | ||
Inner tank dimensions: mm (D×W×H) | 260×280×280 | 360×350×350 | 400×400×450 |
External dimensions: mm (D×W×H) | 440×415×585 | 540×500×710 | 580×540×810 |
Packaging size: mm (D×W×H) | 490×520×710 | 550×600×790 | 600×60×880 |
Partition boards are standard/the most common | 2/4 | 2/4 | 2/4 |
Partition spacing | 44 mm | 60 mm | 80 mm |
Partition load-bearing | 16 kg | ||
