Vacuum Drying Oven (Horizontal)

The vacuum environment significantly reduces the boiling point of the experimental items and can be easily applied to heat-sensitive substances
For samples that are not easy to dry,such as powders or other granular samples,the vacuum drying method can effectively shorten the drying time.
Safer to use:Under vacuum or inert conditions,the possibility of oxide explosion upon heating is completely eliminated.
Compared with ordinary drying that relies on air circulation,powdered samples will not be blown or moved by flowing air.

Send E-mail Get Price

86-175-5409-3886

cedric@cedriccn.com

Description

Technical parameters：

Model	CDT-20A/B/C	CDT-50A/B/C	CDT-90B/C	CDT-210B/C
Capacity	20L	50L	90L	210L
Rated power supply	220V 50HZ
Temp. control range	RT+10°C-250°C
Heating method	Pressure reduction and heating conduction along the four walls
Vacuum degree	<133pa
Temperature resolution	0.1
Temp. fluctuation degree	+/-1℃
Inner liner material	A:Galvanized inner tank,B:201 stainless steel inner tank,C:304 stainless steel inner tank
Shell material	Galvanized sheet(surface electrostatic spraying)
Insulation layer	Ceramic fiber
Heater	Stainless steel eating tube
Material of the observation window	Tempered glass
Vacuum gauge	Silicone oil vacuum pressure gauge
Rated power	600W	1400W	2000W	3000W
Timer	0-9999min
Operation function	Customized operation,timed operation,and automatic stop
Sensor	PT100
Control panel	LED
Inner tank size:mm (D×W×H)	300×300×275	370×415×345	450×450×450	600×550×650
External size:mm(D×W×H)	460×600×460	550×720×540	620×790×670	770×890×930
Packaging size:mm (D×W×H)	525×670×550	840×685×685	910×910×800	910×1070×1165
Partition boards are standard /the most common	2/2	2/2	2/3	3/3
Partition spacing	102mm	119mm	102mm	160mm
Partition weighing	15kg	15kg	15kg	15kg
Optional function	Automatic vacuum gauge,vacuum pump
