Shaking Movement

Orbital

Orbital Diameter

4.5mm

Max. Shaking Weight

(With Accessory)

0.5Kg

Motor Type

Brush less DC motor

Motor Rating Input

18W

Motor Rating Output

10W

Speed Range

Single microplate: 0-1500rpm; Double microplate: 0-1000rpm

Speed Display

Scale

Voltage,Frequency

100-240V,50/60Hz

Power

20W

Permissible Ambient

Temperature And Humidity

5-40℃,80%RH

Protection Class

IP20

Dimension

260*150*80mm

Packing size

470*250*240mm

Net/Gross Weight

3Kg/4kg

for 48 test tubes,Ø6mm(1mL)

for 56 test PCR tubes, strips of 8 , Ø5mm(0.1mL-0.5mL)

Vt1.3.2 Tube Adapter

Cat. No.18900021

Vt1.3.10 Tube Adapter

Cat. No.18900855

for 15 test tubes,Ø10mm(1.5-2mL)

for 4 holes,Ø28mm(50mL)

Vt1.3.3 Tube Adapter

Cat. No.18900022

Vt1.3.11 Tube Adapter

Cat. No.18900862

for 16 test tubes,Ø12mm(5mL)

12*Ø9.8mm+12*Ø6.6mm+12*Ø5mm (1.5/2.0/0.5/0.2mL)

Vt1.3.4 Tube Adapter

Cat. No.18900023

Vt1.3.12 Large Platform

Multi-Specimen Test Tube Adapter

Cat. No.18900875

for 8 test tubes,Ø16mm(10mL)

44 holes*Ø5mm+55 holes*Ø6.6mm+30 holes*Ø9.8mm(1.5/2.0/0.5/0.2mL)

Vt1.3.5 Tube Adapter

Cat. No.18900024

Ps1.1 Universal Top Plate

Cat. No.18900067

for 8 test tubes,Ø20mm(10-15mL)

Used with tube adapters

Vt1.3.6 Platform Pad

Cat. No.18900043

Ps1.2 Single Well Plate Tray Kit Multi-Specimen Test Tube Adapter

Cat. No.18204340

Ø99mm,multiple small tubes and vessels

Work Plate(Suitable for fully-skirted PCR plates, cell culture plates, enzyme immunoassay plates, and deep-well plates. Use with a well plate adapter for half-skirted or non-skirted PCR plates.)

Vt1.3.8 Tube Adapter

Cat. No.18900395

Ps1.3 Double Microplate Clamps

Cat. No.18204341

for 24 holes test tubes, Ø10mm

Double microplate clamps
