UV-visible Spectrophotometer L6

L6 IoT smart UV-visible spectrophotometer, 7-inch touch screen, proportional dual-beam C-T monochromator, wavelength accuracy ±0.3nm, ultra-low stray light. Automatic wavelength, supports cloud storage, WIFI / Bluetooth / USB, can be wirelessly printed and connected to a computer, has stable performance, and is suitable for high-precision UV-visible spectrum analysis.

Send E-mail Get Price

86-15688870591

cedric@cedriccn.com

Description

Product Features:

·7-inch color touch LCD monitor, with a friendly and simple operation interface.

·The machine supports cloud storage function, which can easily scan on WeChat and add the Cloud data program, which greatly facilitates customer application scenarios.

·The machine adopts a high-resolution C-T monochromator,have low stray light (less than 0.1T%), high precision, and high stability (0.002A) that only high-end machines have.

·The machine has powerful storage capabilities, can store 500 data and 30 working curves.

·The world is the first to realize the functions of economical machines that can realize basic measurement, quantitative measurement, data storage and other functions.

·Automatic wavelength setting, automatic light switching setting, and after connecting to computer software, it can realize advanced functions such as wavelength scanning, dynamic measurement, quantitative measurement, nucleic acid measurement, wavelength superposition, integral derivatives, etc.

Product Specification:

Model	L6
Display Method	7-inch high resolution 1024*768 touch screen
Monochromator	Holographic flash grating C-T monochromator,proportional double beam
Grating	1200 wires/mm
Photocell	imported silicon photodiode
Interface	USB & Bluetooth
WIFI module	Support, standard configuration
Wireless printing	Support, wireless Bluetooth printer optional
Connect PC software	Support, optional
IoT module software	Standard, supported
Cuvette holder	Manual 1cm standard
Photometric range	0--200%T, -0.3-3A
Wavelength mode	Automatic
Wavelength accuracy	±0.3nm
Wavelength repeatability	±0.1nm
Spectral bandwidth	2nm
Wavelength range	190-1100
Stray light	0.05T%
Photometric accuracy	±0.5%T, ±0.004Abs (0 ~ 0.5A); ±0.008Abs (0.5 ~ 1A)
Photometric repeatability	±0.5%T, ±0.004Abs (0 ~ 0.5A); ±0.008Abs (0.5 ~ 1A)
Photometric stability	±0.15%T, ±0.002Abs (0 ~ 0.5A); ±0.004Abs (0.5 ~ 1A)
Light switching method	Automatic, 340nm (can be set at will)
Stability	0.001A (500nm, 3min)
Noise	0.15T%
Optional	①Automatic eight-connected cuvette rack or automatic five-connected long-range (5cm) cuvette rack ②DATA special spectral analysis machine software ③5cm or 10cm manual cuvette rack, film sample rack, test tube cuvette rack ④Wireless Bluetooth printer
Packing Size	720600360mm
Weight	19kg
