Tilt Angle

9°

10°

Max. Load Capacity (With Platform)

5kg

2kg

Motor Type

DC motor

DC motor

Motor Input Power

40W

16W

Motor Output Power

24W

10W

Speed Range

10-70rpm

10-80rpm

Speed Display

LCD

LED

Timer Display

LCD

LED

Time Settings Range

1min-99h59min

1min-99h59min

Voltage,Frequency

100-240V, 50/60Hz

100-240V,50/60Hz

Power

50W

20W

Permissible Ambient Temperature And Humidity

5-40℃,80%RH

5-40℃,80%RH

Protection Class

IP21

IP21

Dimension(W*D*H)

360*430*106mm

294*348*170mm

Packing size(W*D*H)

540*490*410mm

420*480*250mm

Net/Gross Weight

9kg/16kg

3.7kg/5kg

18900155

SK330.5,Dish platform with non-slip mat and fixed string (8pcs)Dimension [W*D]:30*28.5cm

18202835

Silicone mattress for 16*5-15mL tubes, use with SK330.5

18202846

Silicone mattress for 6*50mL tubes, use with SK330.5

18900185

SK180.4, Dish attachment with non-slip mat

Dimension [W*D]: 24*21.5cm

18900869

SK330.4 Dish platform with

non-slip mat and fixed string (8pcs),34*34cm

18900859

SK330.6 Transparent shield,

serologic test for syphilis,

41*39.5*10cm

18900860

SK180.5

Transparent

Cover for Syphilis Serum Test, 32*32*8.3cm

18202852

Silicone mattress

for 10*5-10mL tubes

18202853

Silicone mattress

for 4*50mL tubes

18900027

SK330.1,

Universal attachment with 4 bars Size: 32*32cm

Capacity for flask: 25mL*21pcs,

50mL*15pcs, 100mL*12pcs,

250mL*6pcs, 500*4pcs

18900040

SK330.3,

Lengthways roller attachment,Mainly used for separation funnel oscillation extraction applications

500mL*3pcs250mL*4pcs

100/125mL*4pcs50mL*5pcs

18900025

SK180.1,

Universal attachment with 3 bars

Size:25*24.5cm

Capacity for flask: 25mL*10pcs,

50mL*8pcs, 100mL*6pcs,

250mL*4pcs, 500*2pcs

18900038

SK180.3,

Lengthways roller attachment,Mainly used for separation funnel oscillation extraction applications

500mL*2pcs250mL*3pcs

100/125mL*3pcs50mL*4pcs

18900036

Bar for SK330.1

universal attachment

   18900037

Bar for SK180.1

universal attachment

18900280

Connect sticks

for double

dishes shaker

   18900028

SK330.2,Fixing clip attachment

Size:32*32cm

18900026

SK180.2,Fixing clip attachment

Size:25*24cm

18900029

Fixing clip for flask volume 25mL,used with SK330.2[28pcs]

SK180.2[9pcs]

18900030

Fixing clip for flask volume 50mL,used with SK330.2[16pcs]

SK180.2[9pcs]

18900031

Fixing clip for flask volume 100mL,used with SK330.2[16pcs]

SK180.2 [9pcs]

18900032

Fixing clip for flask volume 200/250mL, used with

SK330.2[9pcs]

SK180.2[4pcs]

18900033

Fixing clip for flask volume 500mL, used with SK330.2[9pcs]

SK180.2[2pcs]
