Vacuum drying ovens are used for powder drying,baking, and disinfection and sterilization of various glass containers.It is particularly suit- able for rapid and efficient drying treatment of heat-sensitive,easily decomposable,easily oxidized substances and items with complex components.
86-15688870591
cedric@cedriccn.com
Product Features:
·The vacuum environment significantly reduces the boiling point of the experimental items and can be easily applied to heat-sensitive substances.
·For samples that are not easy to dry,such as powders or other granular samples,the vacuum drying method can effectively shorten the drying time.
·Compared with ordinary drying that relies on air circulation,powdered samples will not be blown or moved by flowing air
·It adopts a microcomputer temperature control system and intelligent PID self-tuning control,featuring temperature control,timing and over-temperature alarm functions.
·It has the functions of memorizing set parameters and recovering from incoming calls.
·The device can automatically resume operation according to the original set program.
Product Specifications:
Model | CDV-50B/C | CDV-90B/C | CDV-210B/C |
Capacity | 50L | 90L | 210L |
Rated power supply | 220V50HZ | ||
Temperature control range | RT+10°C-250°C | ||
Heating method | Pressure reduction and heating conduction along the four walls | ||
Vacuum degree | <133pa | ||
Temperature resolution | 0.1 | ||
Temperature fluctuation degree | +/-1℃ | ||
Inner liner material | B:201stainless steel inner tank,C:304stainess steel inner tank | ||
Shell material | Galvanized sheet(surface electrostatic spraying) | ||
Insulation layer | Ceramic fiber | ||
Heater | Stainless steel heating tube | ||
Observation window | Tempered glass | ||
Vacuum gauge | Silicone oil vacuum pressure gauge | ||
Rated power | 1400W | 2000W | 3000W |
Timer | 0-9999min | ||
Operation function | Customized operation,timed operation,and automatic stop | ||
Sensor | PT100 | ||
Control panel | LED | ||
Inner tank size:mm(D*W*H) | 370*415*345 | 450*450*450 | 600*550*650 |
External size:mm(D*W*H) | 540*610*1240 | 700*640*1570 | 760*780*1780 |
Packaging size:mm(D*W*H) | 660*700*1400 | 715*750*1610 | 950*920*2070 |
Partition boards are standard /the most common | 2/2 | 2/3 | 3/3 |
Partition spacing | 116mm | 102mm | 160mm |
Partition weighing | 15kg | 15kg | 15kg |
Optional function | Automatic vacuum gauge,vacuum pump | ||
