Work Plate Dimension (W*D)

140*140 mm

Ø135 mm(5 inch)

Work Plate Material

Aluminum cover with

ceramic coating

stainless steel cover

with ceramic coating

Motor Type

Brush less DC motor

Brush less DC motor

Stirring Positions

1

1

Max. Stirring Quantity (H₂O)

5 L

3 L

Max. Magnetic Bar (length)

50 mm

50 mm

Speed Range

200-1500 rpm

200-1500 rpm

Speed Display

LCD

LED

Temperature Display

LCD

LED

Heating Temperature Range

Room Temp-380℃

Room Temp-280℃

Heating Liquid Temperature

Control Accuracy

±1℃ (<100℃)

±1% (>100℃)

±1℃ (<100℃)

±1% (>100℃)

Overheating Temperature Protection

420℃

320℃

Temperature Display Accuracy

±0.1℃

±1℃

External Temperature Sensor

PT1000 (accuracy±0.2℃)

PT1000 (accuracy±0.2℃)

"Hot" Warning

-

50℃

Data Connector

-

-

Protection Class

IP21

IP42

Timer Function

-

-

Motor Rating Output

1.8 W

3 W

Power

510 W

515 W

Heating Output

500 W

500 W

Voltage, Frequency

100-120/200-240 V,

50/60 Hz

100-120/200-240 V,

50/60 Hz

Weight

2.2 kg

1.8 kg

Permissible Ambient Temperature And Humidity

5-40℃, 80%RH

5-40℃, 80%RH

Dimension (W*D*H)mm

320*180*108 mm

150*260*100 mm

Packing size (W*D*H)mm

490*350*260mm

470*250*240mm

Weight

2.2 kg/4.6kg

1.8 kg/3.6kg
