High and low temperature circulation devices are mainly used in double-layer glass reactors, reaction devices, combined chemistry and other cold and heat source dynamic constant temperature control, as well as in low-temperature distillation, distillation, extraction.
86-15688870591
cedric@cedriccn.com
Product Features:
·Temperature range: -80~200 °C, customizable high temperature -120~300 °C.
·Fast heating or cooling, the refrigeration heat exchanger adopts a wavy plate type, occupying small space and high efficiency.
·Pre cooling, refrigeration, and heating systems can be used in combination or separately.
·Circulating calibre: DN15(mm)
Product Specification:
Model | Temp. Range | Heating Power | Cooling power | Technical parameters | Power supply | ||||
Temp. accuracy | Temp. fluctuation | Lift | Flow Rate | Medium Viscosity | |||||
GDSZ-5/-20℃ | -20~+200℃ | 3 (kw) | 1.2 (KW) | ±1.0℃ | ±2.0℃ | 20(m) | 35(L/min) | Below 500C·S·t | 220(V)/ 50(Hz) |
GDSZ-5/-40℃ | -40~+200℃ | 1.5 (KW) | |||||||
GDSZ-5/-80℃ | -80~+200℃ | 2.4 (KW) | |||||||
GDSZ-10/-20℃ | -20~+200℃ | 3 (kw) | 1.2 (KW) | ±1.0℃ | ±2.0℃ | 20(m) | 35(L/min) | Below 500C·S·t | |
GDSZ-10/-40℃ | -40~+200℃ | 1.5 (KW) | |||||||
GDSZ-10/-80℃ | -80~+200℃ | 1.5 (KW) | |||||||
GDSZ-20/-20℃ | -20~+200℃ | 6 (kw) | 1.5 (KW) | ±1.0℃ | ±2.0℃ | 20(m) | 35(L/min) | Below 500C·S·t | 380(V)/ 50(Hz) |
GDSZ-20/-40℃ | -40~+200℃ | 1.8 (KW) | |||||||
GDSZ-20/-80℃ | -80~+200℃ | 3.5 (KW) | |||||||
GDSZ-30/-20℃ | -20~+200℃ | 6 (kw) | 2.2 (KW) | ±1.0℃ | ±2.0℃ | 20(m) | 35(L/min) | Below 500C·S·t | |
GDSZ-30/-40℃ | -40~+200℃ | 2.4 (KW) | |||||||
GDSZ-30/-80℃ | -80~+200℃ | 4.4 (KW) | |||||||
GDSZ-50/-20℃ | -20~+200℃ | 9 (kw) | 4.5 (KW) | ±1.0℃ | ±2.0℃ | 20(m) | 35(L/min) | Below 500C·S·t | |
GDSZ-50/-30℃ | -30~+200℃ | 5 (KW) | |||||||
GDSZ-50/-40℃ | -40~+200℃ | 5.5 (KW) | |||||||
GDSZ-50/-80℃ | -80~+200℃ | 11 (KW) | |||||||
GDSZ-100/-20℃ | -20~+200℃ | 9 (kw) | 9 (KW) | ±1.0℃ | ±2.0℃ | 20(m) | 35(L/min) | Below 500C·S·t | |
GDSZ-100/-30℃ | -30~+200℃ | 10 (KW) | |||||||
GDSZ-100/-40℃ | -40~+200℃ | 11 (KW) | |||||||
GDSZ-100/-80℃ | -80~+200℃ | 15 (KW) | |||||||
Heater: The stainless steel heating tube is placed into enclosed pipe heater.
