Small in size, light in weight, and easy to use, it is developed and manufactured on the basis of other models of low-temperature pumps, targeting 1-5-liter rotary evaporators, glass reaction kettles, extraction equipment, as well as other heat exchange cooling devices and heating components for cooling.
86-15688870591
cedric@cedriccn.com
Product Specification:
Product Model | CDL-20 | |
Circulation Method | Sealing cycle | |
Temp. Range | -5℃~38℃ | |
Temp. Control Range | -20℃-RT. | |
Temp. Control Accuracy | ±2℃ | |
Refrigeration capacity | Condition Temp. | 20℃-RT. |
At-10℃ | 900W | |
At-20℃ | 784W | |
Circulation capacity | Max.rate of flow | 16/19L(min) 50/60(Hz) |
Max.Iff of pump | 2.7/3.4(m)50/60(Hz) | |
Temperature controller | Digital Settings, LCD Display | |
Water tank | Capacity aproximatey4L,material SUS304 | |
Cooing coil | Copper(chrome-plating) | |
Circulating nozzle caliber | Outer diameter12mm, inner diameter 8mm | |
External Dimensions | 210*420*530mm | |
Tank Size | 130*250*130mm | |
