Sample capacity

16 well×0.2ml

Temp. control method

Thermoelectronic

Consumable type

0.2 mL 8-strips tubes, Single tube

(the bottom shoulded be transparent)

Ramp rate（max）

6℃/s

Reaction volume

10-100 μL

Temp. accuracy

±0.1℃

Dynamic range

1-10  copies

Temp. uniformity

≤±0.2℃（55℃）

Sample repeatablitity

CV＜1%

Temp. range of hot lid

RT.+5℃-110℃

Sample linear

|r|≥0.999

Temp. gradient range

/

hot lid

Manual hot lid

Time increase/decrease

0.1~9min59s, long PCR is available

Fluorescence channel

5

Temp. Increase/decrease

0.1~9.9℃, touchdown PCR is available

Fluorescence dyes

F1: FAM、SYBR Green I；SYTO 9, EvaGreen，LC Green

F2: VIC、HEX、TET、JOE、TAMRA、CY3、NED；

F3: ROX/TexRed;

F4: CY5；

F5: CY5.5；

Software function

Support absolute quantitative, relative quantitative,melting curve, HRM, SNP and other functions.

Safety protection and alarm

Over heat protection and alarm for block and hot lid

Excitation light source

High brightness and long life LED excitation light source

Data export

Excel, TXT

Detector

PD

Software language

Chinese, English

Excitation wavelength

Channel1:470nm Channel2：523nm Channel3：571nm

Channel4：628nm Channel5：678nm

Voltage range

100-240V

Interface mode

USB

Detection wavelength

Channel1:525nm Channel2：564nm Channel3：612nm

Channel4：692nm Channel5：718nm

Power(max)

350W

Dimension(D*W*H)

330*187*193 mm

Single channel scanning time

＜1s

Net weight (kg)

7.94
