Sample capacity

96 well×0.2ml

Reaction volume

5-100μL

Dynamic range

1-10^10copies

Fluorescence wavelength

320–900 nm

Fluorescence dyes

CH1:FAM、SYBR;
CH2:HEX、VIC、JOE、TET；
CH3:ROX、RED;
CH4:CY5；

CH1:FAM、SYBR;
CH2:HEX、VIC、JOE、TET；
CH3:ROX、RED；
CH4：CY5；
CH5:custom made；
CH6:custom made；

Fluorescence channel

4

6

Excitation source

High-brightness, long-life monochromatic LED module

Optical sensor

High-sensitivity photodiode module (PDM)

Proprietary DDSOM dual-dimensional scanning optoelectronic module

① Each channel is independently excited and detected, resulting in strong signal and low background noise. It is particularly suitable for quantitative real-time PCR experiments using low-concentration DNA reagents such as direct amplification reagents, extraction-free reagents, and rapid extraction reagents.
② All channels are detected in a single scan; all 4 channels require only 16 seconds.
③ Solid-state electron optical data acquisition.

Sensitivity

1 copy

Fluorescence linear correlation

≥0.980

Coefficient of variation

CV ≤3%

Module (Block) temperature range

10-99.9°C

Temperature control technology

 Proprietary semiconductor cooler (Peltier).

Temperature control method

Tube mode (intelligently simulates the actual temperature of the reagent based on the sample volume)

Module temperature control accuracy

≤0.1℃

Temperature accuracy

≤0.2℃

Module temperature uniformity

≤士0.3℃@55℃

Maximum heating/cooling rate

≥4℃/s

Average heating/cooling rate

≥2.5C/s(50~90℃)

Heat cap temperature range

30-105℃，default 105℃。

System operation method

PC Operation (needs to provide their own computer)

Software operating environment

Windows 7/10

Communication interface/network

RS232/USB

Software Functions

① Compatible with multiple reagent types (magnetic bead reagents, turbidity reagents, etc.).
② Supports multiple algorithms for data correction (magnetic bead correction, turbidity correction, crosstalk correction, curve optimization, etc.).
③ Commonly used program templates (pre-denaturation, 3-step amplification, RAA/RPA isothermal amplification, etc.).
④ Firmware upgrade function. Standard curve import and export functions.

Analytical functions

Absolute quantification, relative quantification, melting curve.

Indicator lights

Power on, running, communication, standby status, fault alarm,
hot cover opening alarm.

Product dimensions

430*310*220mm

Packaging dimensions

590*500*440mm

Net/Gross weight

15/20kg
