It is suitable for use in laboratories of industrial and mining enterprises, scientific research institutes, medical and health institutions, etc. for drying, baking, wax melting and heat treatment.
86-15688870591
cedric@cedriccn.com
Product Features:
·The shell is made of high-quality galvanized sheet, and the surface is electrostatic ally sprayed. It has a beautiful and elegant shape, is anti-corrosive and durable.
·The studio is formed by processing 304 stainless steel plates and has undergone anti-corrosion treatment. The height of the shelves is adjustable, and the four comers are semi-arcs, which is convenient for cleaning.
·The all-round three-dimensional forced air supply technology ensures uniform and consistent temperature inside the studio.
·Double-layer tempered glass observation window. The height of the test sample shelf in the working chamber is adjustable, providing clear observation and convenient use.
·The microcomputer intelligent digital display temperature controller has precise temperature control, ensuring no temperature overshoot. It also features functions such as timing and over-temperature alarm.
·Good heat insulation design enables long-term high-temperature operation, has a long service life, is easy to replace, and achieves green, energy-saving and environmental protection to the greatest extent.
·It adopts high-temperature resistant silicone rubber sealing strips and is equipped with a lock-type door lock with adjustable tightness to ensure good sealing performance and prevent heat loss.
·The unique clean geometric cavity design ensures active and perfect protection of the sample.
Product Specifications:
Model | CHP-125C | CHP-210C |
Capacity | 125 L | 210 L |
Rated power supply | 220 V 50 HZ | |
Temperature control range | RT+5°C-65°C | |
Temperature resolution | 0.1 | |
Temperature fluctuation degree | ±0.5°C (At 37°C) | |
Inner liner material | 304 stainless steel inner tank | |
Shell material | Galvanized sheet (surface electrostatic spraying) | |
Insulation layer | Ceramic fiber | |
Heater | Stainless steel heating tube | |
Material of the observation window | Tempered glass | |
Exhaust hole (test hole) | One 35 mm (top) | |
Rated power | 400 W | 500 W |
Timer | 0-9999 min | |
Operation function | Fixed value operation, timed operation, and automatic stop | |
Sensor | PT100 | |
Inner tank size: mm (D*W*H) | 450*500*550 | 500*600*700 |
External size: mm (D*W*H) | 660*630*1055 | 720*735*1200 |
Packaging size: mm (D*W*H) | 720*700*1125 | 745*780*1250 |
Partition boards are standard/the most common | 2/6 | 2/8 |
Partition spacing | 70 mm | 70 mm |
Partition load-bearing | 16 kg | |
