D4600 fully automatic dispensing machine, with ±5μm@3σ high precision, 1200mm/s high-speed operation, supports point/line dispensing, optional multiple valves and automatic cleaning functions, suitable for semiconductor, PCB and consumer electronics dispensing scenarios.
86-15688870591
cedric@cedriccn.com
Product Highlights
Application Fields
Technical Parameters
Items | Parameters |
Dispensing Accuracy | ±5μm@3σ |
Minimum Dot Diameter | 0.2mm |
Dispensing Range | X:400mm,Y:400mm,Z:30mm |
Speed | Up to 1200mm/s |
Dispensing Type | Dot dispensing、Line dispensing |
Adhesive Capacity | Standard 30cc/50cc |
Substrate Thickness | 0.5～10mm |
Substrate Width | 90～150mm |
Substrate Length | Up to 400mm |
Substrate Weight | Up to 3kg |
Nozzle Heating Temperature | RT～100℃ |
Dispenser Valve | Standard configuration:Pneumatic jet valve,Optional configurations:Piezoelectric valve/Screw valve |
Low-Level Alarm | Optional |
Vacuum Cleaning Unit | Optional |
Auto Height Sensing | Optional,Laser non-contact automatic height measurement |
Installation Requirements
Items | Parameters |
Power Supply | 220V@50Hz |
Power Consumption | 3000w |
Compressed Air | 0.4~0.8 Mpa |
Dimension | 1300mm(L)*1250mm(W)*1690mm(H) |
Weight | 1000KG |
